Pan Type Mixers – Erfi Makina – Concrete Batching Plants

Pan Type Mixers

FEATURES	0,5m³ PAN-MİX	1m³ PAN-MİX	1,5m³ PAN-MİX	2m³ PAN-MİX	3m³ PAN-MİX
Loading Capacity	750 LT	1500 LT	2250 LT	3000 LT	4500 LT
Compacted Concrete Capacity	500 LT	1000 LT	1500 LT	2000 LT	3000 LT
Motor Power	18,5 KW	45 KW	60 KW	90 KW	110KW
Reducer	i:1/27	i:1/27	i:1/27	i:1/27	i:1/27
Side Body Abrasions	12 mm Ni Hard	15 mm Ni Hard	15 mm Ni Hard	15 mm Ni Hard	20 mm Ni Hard
Mixer and Scraper Pallets	15 mm Ni Hard	15 mm Ni Hard	15 mm Ni Hard	20 mm Ni Hard	20 mm Ni Hard
Karıştırıcı ve Sıyırıcı Paletler	20 mm Ni Hard	25 mm Ni Hard	30 mm Ni Hard	30 mm Ni Hard 3	30 mm Ni Hard
Automatic In-Mixer Washing system	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE
Water Dispenser	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE
Hydraulic Drain Cover (Standard)	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE
Maintenance Cover Safety Switch	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE
Emergency Stop Button with Switch	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE	AVAILABLE
